S016 Small box

Either way, the date the photo was taken is kept. You can take photos where there is no signal and upload them later with 🖼 Choose photos; the date stays. If the date cannot be read, the taken date is left blank.

Capital letters and digits, starting with a letter (up to 12). Lower case is turned into capitals. If the code already exists, the box joins that one. An administrator can fix names and tidy things up in Settings → Box series.

🎤 You can dictate. Press the microphone on your phone’s keyboard and speak.

Created
2026-09-06 11:00:29
Updated
2026-09-06 16:41:56
🖼 Photos (with IDs) 📋 Items inside (quantity, CSV)
QR

QR code for the label

Download SVG
Label for S016
The label as printed (62.0 × 42.9 mm). Horizontal

Photos of the contents

2026-09-06 11:12:39
仕切りケース全景 — ESP32-WROOM-32 開発ボード×4 / TCA9548A I2Cマルチプレクサ / ADXL345 加速度センサ×2 / ATMEGA328P-PU DIP / 4ch双方向レベル変換 BSS138(LV/HV)×複数 / TXS0108E 8chレベル変換(A/B/OE) / microSDカードリーダ(SPI) / L293D モータドライバ基板 (Deek-Robot) / SOP-DIP変換基板 / USB-シリアル変換(mini-USB) / ユニバーサル基板 / 金属軸ポテンショメータ / ロッカースイッチ×多数
2026-09-06 11:32:35
TCA9548A / NXP PCA9548A — 8ch I2Cマルチプレクサ 同一I2Cアドレスのセンサを8系統に分離して接続
2026-09-06 12:11:54
TXS0108E 8ch双方向レベル変換 (刻印 YF08E / TI) — VA側A1-A8とVB側B1-B8を双方向変換、OEでハイインピーダンス切替
2026-09-06 12:11:56
8chレベル変換基板 AMS1117-3.3 レギュレータ内蔵 (シルク 5V TO 3.3V) — 5V系H1-H8 と 3.3V系L1-L8、471抵抗アレイによる分圧式
2026-09-06 12:11:58
4ch双方向レベル変換 BSS138×4 (刻印 J1Y) — HV1-HV4 と LV1-LV4、I2C等の双方向信号を5V/3.3V間で変換
